Pumps
Pumps for spray systems
.jpg?sfvrsn=4e04c892_1){kind=icon}
Hydrodrive pumps for spray systems
Hydrodrive pressure booster pumps feature Lowara e-HM pumps controlled
by energy efficient Speedmatic inverter drives for long life, maintenance-free operation and up to 70% energy saving over conventional units. The controller varies the speed of the pump in proportion to demand, maintaining constant pressure.
An additional benefit of the Hydrodrive pump design is its dry run protection. In the event of the water supply failing during operation, the pump automatically shuts down to prevent damage to the pump and once the water supply is restored, automatically restarts.
Design Features
- Horizontal multistage centrifugal electric pumps in AISI 302 stainless steel
- WRAS approved components
- Maximum water temperature: 40°C
- IE3 efficient class electric motors
- Class F insulation
- IP55 protection
- Pump casing, impellers, intermediate stages, seal housing disc and shaft in AISI 304 / EN1.4301
- Mechanical seal in Carbon/Ceramic/EPDM
- Technopolymer for HM 305P version
Advantages
- Constant pressure regardless of demand
- Up to 70% energy saving over conventional units
- Dry run protection with auto re-start
- Very quiet operation
- Strong, compact construction
- Factory tested and ready to use
- Plug and go installation
-(2480-x-2000-px).png?sfvrsn=9504c892_1)
